640 series cameras use the latest VGA InGaAsDetector technology, 640×512 high Resolution, in 0.9um~ 1.7umband has extremely high sensitivity. The movement has a very low Dark current and high Dynamic range, and precise TE temperature control further reduces the readout Noise. The whole machine has compact structure, stable performance, small Volume, low Power consumption and strong Environmental conversion. It can be widely used in photoelectric task load, scientific research, security monitoring, machine vision, industrial inspection, system integration and other fields.
Name | High resolution short-wave infrared camera | ||
Model | AC640 | ||
| Detector | |||
DetectorType | 640x 512 InGaAs focal plane | ||
Spectral response | 0.9um~1.7um | ||
As the distance between | 15um | ||
Effective area | 9.6mm×7.68 | ||
Quantum efficiency | >70%@1.0~1.7um | ||
Cooling way | TE1 | ||
| Image | |||
Frame frequency | 25/50/100/300Hz | ||
Exposure time | 1us~1/Frame frequency | ||
Noise | 30e- | ||
Dynamic range | Low gain: 79dB; High gain: 58dB | ||
| Window mode | —— | ||
ADC | 14bit | ||
Image processing | Automatic gain control; Automatic exposure; Non-uniformity correction (set& Gain); Invalid Pixel replacement; Automatic contrast enhancement; | ||
| Interface | |||
Camera control | —— | ||
Digital output | USB /3G-SDI/CameraLink/GigE | ||
External trigger | In or Out(Configurable) | ||
Analog output | PAL/NTSC | ||
| Power supply | |||
Power supply input | 12V±3V DC | ||
Power consumption | ≦4W(TEC off) | ||
| 环境适用性 | |||
Working temperature | -40℃ ~ +70℃ | ||
Storage temperature | -45℃ ~ +80℃ | ||
| Physical properties | |||
Weight | ≤ 300 g (Including Lens front cover) ≤ 240 g (Lens front cover not included) | ||
Size | 68mm×65mm×70mm (Including Lens front cover) 68×65×54.5 mm3 (Lens front cover not included) | ||
Key words:
resolution
temperature
automatic
Classification:
Summary:
High resolution short-wave infrared camera
