The long wave 12μm imaging movement component adopts an uninvert Plan planeDetector with Resolution 640×512, which has Image acquisition, non-uniform correction, Image enhancement and other functions. Belong to low Power consumption, small Volume, low Noise non-refrigeration imaging universal movement components, simple operation, Interface can be changed, convenient assembly in a variety of instruments, to meet the needs of different application scenarios.
Name | Long wave non - Refrigeration imaging movement assembly |
| Detector | |
DetectorType | Uncooled focal plane |
Resolution | 640×512 |
Like yuan spacing | 12μm |
Frame frequency | 50Hz |
Response to the Band | 8μm～14μm |
The startup time | ≤20us |
NETD | ≤20mK@f#1.0, room temperature |
| Image | |
Brightness and contrast adjustment | Manual/automatic |
Points and lines | Load/blanking |
Image processing | Non uniformity correction Image enhancement Background correction |
| Interface | |
Power consumption | ≤1.6W |
Output Interface | Camera Link、PAL、SDL、GigE |
| Environmental adaptability | |
Working temperature | -40℃～60℃ |
Storage temperature | -45℃～70℃ |
Key words:
movement
assembly
correction
Classification:
Summary:
uncooled imaging movement assembly
