Eagle eye series is equipped with high resolution infrared thermal imaging, short-wave infrared imaging, color low illumination of visible light, the human eye safety laser rangefinder and relevant auxiliary function, can free collocation demand effect, electronic compass, beidou/GP positioning and storage system as a whole, is the executive time patrol, secret surveillance, critical infrastructure protection and security tasks necessary in high threat.
Model | Hawkeye 680A- Commander |
Name | Multi-function handheld infrared |
| Focusing on the way | electric |
| Infrared thermal imaging | |
Detector | Detector 640×512, VOx focal plane |
| Response wavelength | 8-14um |
NETD | ≤50mk@F1.0 |
Viewing Angle | 30.4°×23.1°~7.8×5.8° |
| Detection performance | |
Detection range | 2.3×2.3 m2≥5.4km；1.8x0.5 m2≥2.5km |
Identify Distance | 2.3×2.3 m2≥2.5km；1.8x0.5 m2≥1.2km |
| Visible light | |
Detector | 1/3 "color low illuminance CCD |
| The wavelength | —— |
Resolution | 976×582 |
| Minimum illumination | 0.01Lux,F1.2 |
Viewing Angle | 9.8°×5.9° |
| Laser ranging | |
| The laser wavelength | 1.55um, safe for human eyes |
| Distance measuring range | 80m~3000m |
| Ranging accuracy | ≤±3m |
| Satellite positioning | |
| Model | Beidou /GPS dual mode; |
| Positioning accuracy | Latitude and longitude ≤5m, altitude ≤10m |
| Electronic compass | |
| Pitching Angle | -90°~+90° |
| Course Angle | 0°~360° |
Resolution | 0.1° |
| Accuracy of measurement | 0.5°RMS |
| Laser indicator | |
| Type | 635nm,10mW Class IIIB |
| Power supply performance | |
| The power supply | 12.6V Power Supply adapter with built-in lithium battery |
| Battery life | ≥8h@25℃ |
| Image | |
| Output video system | PAL |
| Infrared electron amplification | 2X/4X |
| Infrared polarity | White/black heat, false color |
| Brightness/contrast | Automatic/manual |
| Image enhancement | Automatic Image filtering and sharpening |
| Display/eyepiece performance | |
| Display | —— |
| Eyepiece diopter | —— |
| Wireless figure pass | |
| The wireless network | Encryption WiFi |
Transmission Distance | 50-100m(Open without shelter) |
| Supported operating systems | Android/I0S |
| Storage performance | |
Storage | Built-in 16GBSD card, can store not less than 10000 still pictures, not less than 2 hours of video |
| Take photos/video | Single button, short press photo, long press video |
| Interface performance | |
Electrical Interface | —— |
Electrical Interface define | Power Supply (simultaneous Power supply/charging), USB (export photo/video data), PAL video |
Mechanical Interface | 1/4-20' standard tripod Interface |
| Physical properties of | |
Weight | 2.5kg（±10%） |
Size | 244mm×183mm×113mm |
| Appearance of the color | The top cover is earthy yellow and the main body is black |
| Environmental adaptability | |
Working temperature | -20℃~+60℃ |
Storage temperature | -40℃~+70℃ |
Protection grade | IP67 |
| Fall | Resist 1 meter drop |
MTBF | —— |
